perch.media

The media provider wraps the platform’s session APIs (MPRIS on Linux, GSMTC on Windows) into one model. Read side under scope media, verbs under media.control.

The model

on_media(host, m) — scope media

The event stream. Fires on every state change and position poll (~2/s while playing), always with the current model.

function M.on_media(host, m)
  host.set_presence("nowplaying", m.hasPlayer, {
    title = m.title, artist = m.artist, artUrl = m.artUrl,
    playing = m.playing,
    posFrac = m.dur > 0 and m.pos / m.dur or -1,
  })
end

perch.media.read() — scope media

local m = perch.media.read()

Pull the last full model. One use case: seeding on_start so a package starting mid-song doesn’t wait for the next event.

perch.media.control(verb) — scope media.control

perch.media.control("playPause")
perch.media.control("seek:132")     -- absolute seconds, integer

The verb list is a hard whitelist — anything else is refused and logged. Wiring a seek bar end-to-end:

-- displays.lua
{ type = "bar", bind = "posFrac", seek = true, knob = true, action = "seek:{frac}" }

-- logic.lua  (frac arrives 0..1; the verb wants seconds)
function M.on_command(host, widget, action)
  if action:sub(1, 5) == "seek:" then
    perch.media.control("seek:" .. math.floor(tonumber(action:sub(6)) * dur))
  end
end

The visualizer

You don’t get raw audio — the viz component’s level feed is produced by the core capture pipeline (running only while something plays) and arrives through the builtin media payload. For your own widgets, drive a viz with any 0–1 level array you compute.
